n8n workflows: how they actually work.

What an n8n workflow is

n8n is a workflow automation tool you can run on your own server. You build automations visually on a canvas: each box is a node, the lines between them are the path the data takes, and the whole thing is triggered by a schedule, a webhook, an event in another app, or a button you press.

Where it differs from the hosted connectors most people meet first is ownership. You can self-host it, which means execution volume stops being a billing event and your data never leaves infrastructure you control. It is fair-code licensed rather than fully open source: the source is available and self-hosting for your own business is free, with restrictions on reselling it as a service.

The other difference is depth. A workflow can branch, loop, call sub-workflows and drop into JavaScript or Python whenever the visual nodes run out of expressive power. That makes it viable for real business logic rather than only for glue between two SaaS apps — and it is why we default to it when a client needs serious automation without a licence per task.

The core concept

How data moves between nodes

This is the part worth reading twice, because almost every confusing n8n behaviour traces back to it. Data travels as an array of items. Each item is an object with a `json` property holding your actual data, and optionally a `binary` property for files.

Most nodes run once per item automatically. If a node outputs fifty items, the next node executes fifty times — you do not write a loop for that, it is the default behaviour. That is why fetching fifty rows and then calling an API "once" quietly makes fifty API calls.

The corollary catches everyone at least once: if a node outputs zero items, every node after it simply does not run. Nothing errors, nothing is logged as a failure, the execution just ends early and looks successful. When a workflow "does nothing" with no error, an empty item array is almost always why.

{{ $json.email }}
// A field on the item currently being processed.

{{ $('Fetch Orders').item.json.total }}
// The matching item from an earlier node, by node name.

{{ $now.minus({ days: 7 }).toISO() }}
// Dates use Luxon. Handy for "everything since last week" filters.

{{ $json.lines.map(l => l.sku).join(', ') }}
// Plain JavaScript works inside expressions.

When a branch needs data from two different paths, the Merge node joins them — by position, by a matching field, or by simply appending one set to the other. Reaching for the Merge node is usually the fix when a workflow "loses" fields halfway through: the data did not disappear, it went down a different branch.

Examples

Three workflows worth copying

These are shapes we build repeatedly for clients. None of them needs a Code node, and all three are a few hours of work once the credentials exist.

• Inbound lead to CRM to Slack — Webhook trigger → validate the payload → look up whether the company already exists → create or update the CRM record → post to the sales channel with the enrichment attached.
• Nightly report from two systems — Schedule trigger → query the database → fetch yesterday's figures from an API → Merge by date → format → email the summary and write the row to a sheet.
• Document inbox to structured data — Email trigger with attachment → extract the file → send it to an AI extraction step → validate the fields against rules → post to your accounting system, or route to a human if confidence is low.
• Sub-workflow for the shared part — The "notify a human and wait" logic lives once in its own workflow and is called by the other three via Execute Workflow. Change it once, every caller gets it.

When nodes are not enough

The Code node, and when to reach for it

The Code node runs JavaScript (or Python) over the items passing through. It has two modes and picking the wrong one is a common source of confusion: "Run Once for All Items" gives you the whole array to work with, while "Run Once for Each Item" gives you a single item and runs repeatedly.

Use it for reshaping data, non-trivial filtering and calculations that would take six visual nodes to express. Do not use it as a place to call APIs and hide half the workflow — the value of a visual workflow is that someone else can read it, and a hundred-line Code node throws that away.

// Keep only the big orders, and reshape them for the next node.
const items = $input.all();

return items
  .filter((item) => item.json.total > 100)
  .map((item) => ({
    json: {
      id: item.json.id,
      customer: item.json.customer.name,
      total: item.json.total,
    },
  }));

Every Code node must return an array of items shaped like { json: {...} } — returning a bare object is the most common error here.

Production

Error handling: the part that decides if it survives

A workflow that works on the happy path is a demo. What makes it a system is what happens when an API rate-limits you, a token expires, a field arrives null, or a third party has a bad afternoon. n8n gives you four mechanisms and a production workflow generally uses all four.

• Retry on fail — Per node: number of attempts and the wait between them. Fixes the majority of transient API failures on its own.
• Continue on fail — Lets the workflow carry on past a node that errored, so one bad record does not kill a batch of five hundred.
• Error workflow — A workflow-level setting pointing at a second workflow that runs when this one fails — where you put the alerting.
• Error Trigger node — The entry point of that error workflow. It receives what failed, in which node, with which data.

The other half is idempotency. If a workflow can run twice on the same input — and eventually it will, through a retry or a duplicate webhook — it must not create the invoice twice. Keying on an external ID and checking before creating is boring and it is what separates automation people trust from automation people quietly turn off.

Running it

Self-hosted or n8n Cloud

Both are legitimate. The decision is usually about data and volume rather than about features, since the editor and the nodes are the same either way.

If you self-host, three settings matter more than the rest: set a persistent encryption key before creating any credentials — regenerate it later and every stored credential becomes unreadable; turn on execution data pruning, because execution history grows without limit and will eventually fill the disk; and put it behind a proper reverse proxy with the webhook URL configured, or your webhook nodes will hand out addresses nobody can reach.

Comparison

n8n vs Zapier vs Make

They overlap more than their marketing suggests. The honest split is that hosted connectors are faster to start and priced per unit of work, while n8n costs more setup and then stops charging you for volume.

Our rule of thumb: three simple connections between popular SaaS apps and nobody to run a server, use a hosted connector. Steady volume, sensitive data or logic with real branching, use n8n. A legacy system with no API at all is neither — that is an RPA problem.

From experience

The mistakes we see most

Every one of these has cost somebody a weekend, including us.

• Building in production — Test executions hitting live systems. Use test credentials and a staging path, or you will email real customers.
• Ignoring the item model — A node that "runs once" actually running per item, quietly making hundreds of API calls.
• No error workflow — Failures nobody notices for a week, because the workflow is silent when it dies.
• Everything in one workflow — A canvas with eighty nodes that nobody dares change. Split it and call sub-workflows.
• No version control — Workflows only exist inside the instance. Export the JSON into a repository so changes are reviewable and revertible.
• Losing the encryption key — Rebuild the container without persisting it and every credential has to be entered again.
